Teflon Terminal
[FN Series] (10pcs/pack) |
|---|
| Material | Metal part | Brass |
|---|---|---|
| Resin part | Teflon (UL94V-0) | |
| Finish | Upper side | Sn plating over Ni |
| Lower side | Ni plating | |
| Withstand voltage | 2000V AC, DC 1min | |
| *FN-1-0 | |
| |
| *FN-1-1 | |
| |
| *FN-1-2 | |
| |
| *FN-1-3 | |
| |
| *FN-2-1 | |
| |
| *FN-2-2 | |
| |
| *FN-2-3 | |
| |
| *FN-3-1 | |
| |
