Board To Board Connector (Angle Type)
[OZ-001] (10pcs/pack) |
|---|
|
| EXAMPLE |
|---|
|
|
| Material | Resin part | PBT red (UL94V-0) |
|---|---|---|
| Pin part | Brass | |
| Finsh | Pin part | Au plating over Ni |
| Recommended through-hole diameter (phi mm) | 0.8 | |
| Temperature range (degrees Celsius) | -40 to +125 | |
| Applicable socket pin | PM-1 | |
 |
